Copper mould tube

Square, Rectangular, Round and Beam Blank copper mould tubes. With dedicated to research of new technologies, we continuously develop various sizes, materials and special shapes, large and super large size mould tubes.

LMM Brand Copper Mould for continuous casting machine in steelmaking is available for :
billet caster, bloom caster, beam blank caster, slab/thin slab caster.

Various sizes and types of copper mould tubes and plates have been supplied to world’s top steel manufacturer Arcelormittal, TATA Steel, EZZ steel etc. We do OEM for Concast and Danieli for a long time

Name

Size/ltem

CAMBER RADIUS

THICKNESS

LENGTH

REMARKS

Square & RectangleCopper tubes

Square 50×50~650×650 Rectangle (100-500) ×650

3000 ~ 17000

6-50

602-1100

With slot single taper,doubletaper,triple taper,quadruplicatetaper,parabolic taper and variuskinds of continuous taper higheffciency copper mould tubes

Round copper tubes

2110-01500

5000-17000 Also straight

10-50

602-900

With slot double taper, quadruplicate taper.parabolictaper and varius kinds of

continuous  taper high effciency copper mould tubes

Non-standardcopper mould tubesBeam Blank coppermould tubes

535-150×120-70

6000-14000

12-50

700-1016

With slot single taper,doubletaper,triple taper.quadruplicatetaper,parabolic taper

Special product design, please send specific data and drawings to our mailbox or form.
